STEREO HYBRID 140 HPC
PRO 750
Tough day out on the trails? It's better than a tough day in the office and, anyway, you've got the perfect wingman in the form of the Stereo Hybrid 140 HPC Pro 750. Featuring a 750Wh battery and the Bosch CX drive unit with up to 85Nm of torque it's ready for miles of trail smiles. Shimano's Deore 1x11 gears get your power to the trail via grippy Schwalbe 2.6in tyres, and there's a set of powerful Magura MT Thirty hydraulic four-piston disc brakes to put you firmly in control. With a 150mm RockShox Recon Silver air fork up front and 140mm of travel out back from the Deluxe Select shock, you're all set.
AUSSTATTUNG
| FRAME | C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Fully Integrated Battery, Advanced Internal Cable Routing |
|---|---|
| SIZE | Size Split: 27.5: S // 29: M L XL |
| SUSPENSION FORK | RockShox Recon Silver RL Air, Tapered, 15x110mm, eMTB Approved, 150mm, Lockout |
| SHOCK | RockShox Deluxe Select, 205x60mm (27.5: 185x55mm), Rebound Adjust, Trunnion Mount |
| SHOCK HARDWARE | Top: 54mm Trunnion Mount, Bottom: 22.2x8mm |
| BRAKE SYSTEM | Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203) |
| REAR DERAILLEUR | Shimano Deore RD-M5100-SGS, 11-Speed |
| SHIFTERS | Shimano Deore SL-M5100, Rapidfire-Plus |
| CRANKSET | ACID E-Crank, 165mm (27.5: 36T // 29: 34T) |
| CHAIN GUIDE | Reverse Flip-Guide E-Chain Guide, Direct Mount, GEN4 |
| CASSETTE | Shimano Deore CS-M5100, 11-51T |
| CHAIN | KMC X11 |
| FRONT HUB | Shimano HB-MT400-B, 15mm, Boost, Centerlock |
| REAR HUB | Shimano FH-MT400-B, 12mm, Boost, Centerlock |
| RIMS | Rodi Tryp 30, 32H, Disc, Tubeless Ready |
| TYRES | Schwalbe Nobby Nic, PerfL, 2.6 |
| STEM | CUBE Performance Stem E-MTB, 31.8mm |
| HANDLEBAR | Newmen Evolution SL 318.25, 760mm |
| GRIPS | ACID React Pro |
| SEAT POST | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| SADDLE | Natural Fit Venec |
| HEADSET | ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
| WEIGHT | 24,5 kg |
| COLOUR | frostwhite´n´grey |
| DRIVE UNIT | Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System |
| BATTERY | Bosch PowerTube 750 |
| REMOTE | Bosch LED Remote |
| CHARGER | Bosch 2A |
| ART. NO | 736130 |
GEOMETRY
What good is a go-anywhere, ride-all-day, Bosch-powered bike without power? Not much, which is why every frame size of the Stereo Hybrid 140 HPC, right down to the smallest, accepts a 750Wh battery. Combined with up to 85Nm from the Bosch CX drive unit, it's your ticket to extended off-road adventures. The Boost 148 rear axle, large pivot bearings and All Mountain Geometry deliver assured handling, even when you're exploring the limits of the 140mm rear and 150mm front travel. Sram's UDH gear hanger helps protect against crash damage and is easily replaceable. And Internal Cable Routing reduces maintenance and complements the clean lines of the full carbon main frame.
