REACTION HYBRID

PRO 500 ALLROAD

The Reaction Hybrid Pro Allroad is the Swiss Army knife of Bosch-powered e-bikes. The high-capacity PowerTube battery and smooth power delivery of Bosch's Purion-controlled, fourth-generation CX drive unit is ideal for weekend exploring. Shimano's Deore 1x11 transmission gives you precise gear shifting and a wide range for tackling any route, while powerful Shimano hydraulic disc brakes and 2.35in Schwalbe tyres ensure you're always in control. The X-Fusion air suspension fork smooths the path ahead, wherever your riding takes you. And, for weekday commuting or errands across town, the full-length mudguards, kickstand and integrated lights add real-world practicality.

AUSSTATTUNG

FRAMEAluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Internal Cable Routing, Full Integrated Battery, Kickstand/Fender/Carrier Mounting Points
SIZESize Split: 27.5: XS (13.5"), S (15") // 29: M (17"), L (19"), XL (21"), XXL (23"); Trapeze: 27.5: S (15") // 29: M (17"), L (19")
FORKX-Fusion MIG32 Air, Tapered, 15x110mm, 100mm, Lockout
SUSPENSION FORKX-Fusion MIG32 Air, Tapered, 15x110mm, 100mm, Lockout
BRAKE SYSTEMShimano BR-MT200, Hydr. Disc Brake (180/180)
REAR DERAILLEURShimano Deore RD-M5100-SGS, 11-Speed
SHIFTERSShimano Deore SL-M5100, Rapidfire-Plus
CRANKSETACID E-Crank, 175mm, 38T
CASSETTEShimano Deore CS-M5100, 11-51T
CHAINKMC X11
FRONT HUBShimano HB-MT400-B, 15mm, Boost, Centerlock
REAR HUBShimano FH-TX505, QR, Centerlock
RIMSCUBE EX30, 32H, Disc, Tubeless Ready
TYRESSchwalbe Smart Sam, Active, K-Guard, 2.35
STEMCUBE Performance Stem E-MTB, 31.8mm
HANDLEBARCUBE Rise Trail Bar, 720mm
GRIPSACID React Pro
SEAT POSTCUBE Performance Post, 30.9mm
SEAT CLAMPCUBE Varioclose, 34.9mm
SADDLENatural Fit Sequence
HEADSET27.5: ACROS AZX-1032, BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) // 29: ACROS AZX-1030, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
PEDALSACID PP MTB
FRONT LIGHTCUBE Shiny 50 Lux, 12V, DC
REAR LIGHTACID Mudguard Rear Light PRO-E, 12V, DC
KICKSTANDCUBEstand Cmpt
MUDGUARDSACID 75 BB-Mount
BELLEasy Bell
CARRIERACID Gepäckträger Rail, SIC
WEIGHT24,6 kg
COLOURdesert´n´orange
DRIVE UNITBosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt)
BATTERYBosch PowerTube 500
DISPLAYBosch Purion
CHARGERBosch 2A
ART. NO534161

GEOMETRY

It's all in the detail. The Reaction Hybrid's PowerTube frame design contains the high-capacity Bosch battery and sophisticated, fourth-generation CX motor - giving you the power to take on any ride. Agile Ride Geometry and a 1.5in head tube deliver impeccable, confidence-inspiring handling. Internally routed cables reduce maintenance and help keep gear shifts clean and precise. The Trapeze frame option and full Size Split breakdown means there's a Reaction Hybrid to suit everyone. And for the Allroad, we added practical full-length mudguards, a kickstand and integrated lighting system for extra versatility.
