REACTION HYBRID
SL 625 ALLROAD 29
With the compact Reaction Hybrid SL 625 Allroad 29 you'll be able to take the road less travelled, wherever it leads. Bosch's fourth-generation CX drive unit and 625Wh battery serve up mile after mile of dependable pedal assistance. Fox's 34 AWL fork smooths the way ahead, while Shimano's slick-shifting XT 1x12 gears put you in full control. Full-length mudguards and a luggage carrier add stacks of practicality. And the integrated light set and powerful, four-piston Shimano hydraulic disc brakes ensure your safety in all conditions and at any time of day.
AUSSTATTUNG
| FRAME | Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Internal Cable Routing, Full Integrated Battery, Kickstand/Fender/Carrier Mounting Points |
|---|---|
| SIZE | S (15"); Trapeze: S (15") |
| FORK | Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm |
| SUSPENSION FORK | Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm |
| BRAKE SYSTEM | Shimano BR-MT420, Hydr. Disc Brake (203/203) |
| REAR DERAILLEUR | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| SHIFTERS | Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus |
| CRANKSET | ACID E-Crank, 175mm, 38T |
| CASSETTE | Shimano Deore CS-M6100, 10-51T |
| CHAIN | Shimano CN-M6100 |
| FRONT HUB | Shimano HB-MT400-B, 15mm, Boost, Centerlock |
| REAR HUB | Shimano FH-MT410-B, 12mm, Boost, Centerlock |
| RIMS | CUBE EX30, 32H, Disc, Tubeless Ready |
| TYRES | Schwalbe Smart Sam, Active, Kevlar, 2.6 |
| STEM | CUBE Performance Stem E-MTB, 31.8mm |
| HANDLEBAR | CUBE Rise Trail Bar, 720mm |
| GRIPS | ACID React Pro |
| SEAT POST | CUBE Performance Post, 30.9mm |
| SEAT CLAMP | CUBE Varioclose, 34.9mm |
| SADDLE | Natural Fit Sequence |
| HEADSET | ACROS AZX-1030, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
| PEDALS | ACID PP MTB |
| FRONT LIGHT | ACID Front Light PRO-E 110, 5-16V, DC |
| REAR LIGHT | ACID Mudguard Rear Light PRO-E, 12V, DC |
| KICKSTAND | CUBEstand Pro, Adjustable |
| MUDGUARDS | ACID 75 BB-Mount |
| BELL | Knog Oi |
| CARRIER | ACID Gepäckträger Rail, SIC, 29" Boost |
| WEIGHT | 25 kg |
| COLOUR | black´n´metal |
| DRIVE UNIT | Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt) |
| BATTERY | Bosch PowerTube 625 |
| DISPLAY | Bosch Kiox |
| CHARGER | Bosch 4A |
| ART. NO | 534332 |
GEOMETRY
Our smallest Reaction Hybrid frame is built around the powerful, versatile 625Wh battery. More compact and lighter than the battery featured in the larger frame sizes, it allows us to create the perfect Agile Ride Geometry for shorter riders without compromising performance or comfort. The result is a bike that's a perfect match to your body size. It's also lighter, easier to handle and huge fun, with the motive force of Bosch's proven fourth-generation drive unit giving your legs and lungs a boost. Full-length mudguards, our Acid carrier system, kickstand and lights add extra practicality. And it still has all the features you'd expect, like internal cable routing - with provision for a dropper post - and a 1.5in head tube for precise, confidence-inspiring steering.
