COMPACT SPORT HYBRID

500

Getting from A to B doesn't need to involve sitting in a tin box - and here's the proof. The Compact Sport Hybrid's rugged, easy step-through design fits riders of all sizes and is easy to store and transport. Bosch's powerful Performance drive unit takes the sweat out of everyday riding, while Shimano's wide-ranging and reliable 10-speed Tiagra gears make light work of any route. Powerful hydraulic disc brakes ensure you can stop safely in all weathers. And the lighting system, mudguards, luggage carrier and kickstand ensure that the Compact Sport Hybrid will slot easily into your life. For work, for play, for any reason.

AUSSTATTUNG

FRAMEAluminium Superlite, Comfort Ride Geometry, Semi-Integrated Carrier, Double Butted, Front-Carrier Ready, Slider Dropout
SIZEOne Size
FORKAluminium 20"
BRAKE SYSTEMShimano BR-MT200, Hydr. Disc Brake (180/160)
REAR DERAILLEURShimano Tiagra RD-4700GS, 10-Speed
SHIFTERSShimano Tiagra SL-4700
CRANKSETACID E-Crank, 165mm, 44T
CASSETTEShimano CS-HG500, 11-34T
CHAINKMC X10
FRONT HUBShimano HB-TX505, QR, Centerlock
REAR HUBShimano FH-TX505, QR, Centerlock
RIMSCUBE EX30, 32H, Disc, Tubeless Ready
TYRESSchwalbe Super Moto-X, Double Defense, 62-406
STEMBySchulz Speedlifter Twist Pro SDS T15
HANDLEBARCUBE Comfort Trail Bar, 680mm
GRIPSNatural Fit Comfort
SEAT POSTNewmen Evolution, 27.2mm
SEAT CLAMPCUBE Varioclose, 31.8mm
SADDLENatural Fit Sequence
HEADSETCube H835D3, Semi-Integrated, Sealed bearing
PEDALSCUBE PP MTB
FRONT LIGHTCUBE Shiny 50 Lux, 12V, DC
REAR LIGHTHerrmans H-Trace
KICKSTANDCUBE CenterStand
MUDGUARDSACID 75 Compact
BELLRing Bell
CARRIERACID 20" Semi-Integrated Carrier, ACID RILink Adapter Compatible
WEIGHT23,2 kg
COLOURblack´n´polarsilver
DRIVE UNITBosch Drive Unit Performance Generation 3 (65Nm) Cruise (250Watt)
BATTERYBosch PowerPack 500
DISPLAYBosch Purion
CHARGERBosch 2A
ART. NO589150

GEOMETRY

At CUBE we know that the simplest solutions are often the best. The Compact Hybrid's cross-braced down tube is elegant, stiff and strong. It also makes this an easy bike to step in and out of, as well as providing a convenient carrying handle. There's a long head tube for accurate, safe steering. The smooth and powerful Bosch drive unit lives in a custom housing at the bottom of the frame, with the battery tucked out of the way of both luggage and rider. Quick and easy saddle and handlebar adjustments allow one bike to fit the widest possible range of riders. And the front luggage carrier increases carrying capacity and adds even more versatility. For commuting, for popping to the shops, for camping, for exploring. For you.
