AIM
Fat-tyred adventures start with a bike that you can rely on; a companion that'll be with you over every pebble, rock and root. We built the Aim with this in mind, using our expertise in aluminium frame building to create a bike with a comfortable ride and intuitive, safe handling. Then we added a reliable set of components including a comfortable Suntour suspension fork and, new for 2018, powerful mechanical disc brakes. The result is a bike that'll inspire you to explore, wherever the trail leads. And with our Size Split system, there's a frame size to suit every rider.
AUSSTATTUNG
| FRAME | Aluminium Lite, AMF, Internal Cable Routing, Easy Mount Kickstand Ready |
|---|---|
| SIZE | 27.5: 14", 16", 18" // 29: 17", 19", 21" |
| FORK | SR Suntour XCT Coil, 100mm |
| BRAKE SYSTEM | Tektro MD-280, Mech. Disc Brake |
| REAR DERAILLEUR | Shimano RD-TX800, 8-Speed |
| FRONT DERAILLEUR | Shimano FD-T700-TS6, Downswing, 31.8mm |
| SHIFTERS | Shimano ST-EF51, EZ Fire Plus |
| CRANKSET | Shimano FC-T501, 42x32x22T, 170mm |
| CASSETTE | Shimano CS-HG200, 12-32T |
| CHAIN | KMC Z7 |
| FRONT HUB | CUBE Alloy Light |
| REAR HUB | CUBE Alloy Light |
| RIMS | CUBE SD20, 32H, Disc |
| TYRES | Schwalbe Smart Sam, Active, 2.1 |
| HANDLEBAR | CUBE Rise Trail Bar, 680mm |
| GRIPS | CUBE Performance Grips |
| SEAT POST | CUBE Performance Post, 27.2mm |
| SEATCLAMP | CUBE Varioclose, 31.8mm |
| SADDLE | CUBE Active 1.1 |
| HEADSET | CUBE No.10 Semi-Integrated |
| PEDALS | CUBE PP MTB |
| WEIGHT | 14,5 kg |
| COLOUR | kiwi´n´black |
| ART. NO | 101110 |
GEOMETRY
Safe, predictable handling is the backbone of any bike. That's why we started with our renowned compact Agile Ride Geometry, for a perfect blend of lively handling and a relaxed, comfortable ride position. To make sure that all your effort is translated into forward progress, we added a cross-ovalised down tube for extra stiffness, made from 6061 aluminium using our Advanced Mechanical Forming Process. It's one of many features that makes the Aim frame light, but exceptionally strong. And to really show off the frame's looks - and keep it looking good for many years to come - we finished off with several layers of paint in our simple but bold kiwi 'n' black colour scheme.
