STING WS 140 HPC
RACE
Big days out in big country demand a bike that's up to the task. Borrowing technology we developed partly out of experience born from racing mountain bikes on some of the planet's most challenging trails, the Sting WS 140 HPC Race doesn't hold back in helping you get the best out of your trail riding. The carbon main frame is available in sizes right down to 13.5 inch, which means every rider should be able to find her perfect fit. The tapered head tube and refined geometry are designed to cater specifically for a 150mm fork and, like all our frames, it's flown through the torture-testing processes of our own in-house, 24/7 test lab. The easily adjustable Fox 34 Rhythm fork and Fox Float DPS EVOL shock work in tandem to smooth your way down even the gnarliest trail, while grippy Schwalbe tyres and powerful Magura MT Trail hydraulic disc brakes give you the bite and control you need to keep your speed in check. We selected a light, strong and stiff Fulcrum wheelset, and Shimano's superb and wide-ranging 1x12 transmission puts an absolutely enormous range of gears right by your right thumb. Yes, it really is that easy. Put it all together and the Sting WS 140 HPC Race is every woman's ticket to longer, more adventurous rides - whether you're tackling steep switchbacks or a fast, rolling singletrack descent. Sounds fun, right?
AUSSTATTUNG
| FRAME | HPC Carbon Monocoque Advanced Twin Mold Technology, Aluminum 6061 T6 Rear Triangle, ATG, ETC 4-Link, ISCG Mount, Boost 148, AXH |
|---|---|
| SIZE | 13,5", 16", 18", 20" |
| FORK | Fox 34 Rhythm, Tapered, 15x110mm, 150mm, 2-Position Sweep-Adjust Grip Damper |
| SHOCK | Fox Float DPS EVOL, 185x52.5mm Trunnion Mount, Open/Medium/Firm Mode |
| SHOCK HARDWARE | Top: 54mm Trunnion Mount, Bottom: 22x8mm |
| BRAKE SYSTEM | Magura MT Trail Custom (180/180) |
| REAR DERAILLEUR | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| SHIFTERS | Shimano XT SL-M8100 |
| CRANKSET | Shimano XT FC-M8100, 32T, Boost, 170mm |
| CASSETTE | Shimano SLX CS-M7100, 10-51T |
| CHAIN | Shimano CN-M7100 |
| WHEELSET | Fulcrum Red Zone 700 Boost, 28/28 Spokes, 15x110mm/12x148mm, Tubeless-Ready |
| TYRES | Schwalbe Nobby Nic, Addix Speedgrip, Kevlar, Tubeless Easy, 2.35 |
| HANDLEBAR | Newmen Evolution 318.20, 760mm |
| GRIPS | CUBE Race SL Grip 29.5mm, 1-Clamp |
| SEAT POST | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm, 13.5" 370x100mm, 16" 420x125mm, 18" & 20" 480x150mm |
| SEATCLAMP | CUBE Screwlock, 34.9mm |
| SADDLE | Natural Fit Venec WS |
| HEADSET | FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2" |
| WEIGHT | 12,7 kg |
| COLOUR | carbon´n´rubinred |
| ART. NO | 328300 |
GEOMETRY
All our carbon frame-building expertise is poured into the Sting 140 HPC's elegant, light and incredibly stiff front triangle. Internal cable routing keeps your gear shifts clean and your time clear for riding, not fiddling with maintenance tasks. The tapered head tube and refined geometry are designed to cater specifically for the demands of a 150mm fork - so you'll always be in full control, no matter how tough the trail. At the rear, we've applied all our aluminium know-how into a stiff, strong and lightweight structure that works seamlessly with the rest of the frame. Short chain stays serve up superb climbing performance, and the steep seat angle and long reach are part of the package that we designed specifically to deliver sharp, safe and confidence-inspiring handling. Ride more, whatever that means for you.
