STEREO HYBRID 160 HPC

SLT 625 27.5

Top-level performance demands top-level components. At CUBE we understand that - it's the reason we developed the Stereo Hybrid 160 HPC SLT. An enduro hybrid built to perform at the highest level, it combines the rock-solid handling and refined, progressive suspension kinematics of our new Stereo Hybrid 160 HPC frame with a wish-list of components that would have even the most pampered of factory team riders salivating. Sram's new XO1 Eagle AXS wireless transmission sets new standards for gear range, simplicity and functionality, pairing seamlessly with Bosch's awesome fourth-generation CX drive unit to deliver smooth, pedal-assisting torque to the rear wheel. Thanks to our new Modular Battery System, the CUBE engineering team was able to make room inside the down tube for an even higher capacity Bosch power unit, ensuring that you've got the range you need for longer days out in the mountains. The RockShox Super Deluxe Ultimate shock and matching Lyrik Ultimate fork perform as well as you'd expect from their names, serving up huge amounts of plush, progressive, rock-swallowing travel and keeping the light, tough Newmen Advanced wheels and extra-wide Schwalbe 2.6in Super Gravity tyres firmly anchored to the ground, except when you don't want them to be. Backing up all this stellar control is a RaceFace cockpit, wireless Reverb Stealth AXS dropper post and powerful four-piston Magura MT7 hydraulic disc brakes running on oversized 203mm rotors. With frame, Bosch drive system and Sram transmission components working this flawlessly together, there's no trail you won't be able to tackle. Faster, higher, longer - the Stereo Hybrid 160 HPC SLT will take you there.

AUSSTATTUNG

FRAMEC:62 Monocoque Advanced Twin Mold Technology, Aluminum 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, Full Integrated Battery
SIZE16", 18", 20", 22"
FORKRockShox Lyrik Ultimate RC2, 15x110mm, eMTB Approved, 170mm
SHOCKRockShox Super Deluxe Ultimate, 205x60mm, Trunnion Mount
SHOCK HARDWARETop: 54mm Trunnion Mount, Bottom: 22.2x8mm
BRAKE SYSTEMMagura MT7, Hydr. Disc Brake (203/203)
REAR DERAILLEURSram X01 Eagle™ AXS, 12-Speed
SHIFTERSSram Eagle AXS™ Controller
CRANKSETe*thirteen Plus Crank, 36T, 165mm
CHAIN GUIDEe*thirteen Plus e*spec
CASSETTESram XG-1299 Rainbow, 10-50T
CHAINSram PC-X01 Eagle™
WHEELSETNewmen Advanced SL E.30 Carbon, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready
FRONT TIRESchwalbe Magic Mary Kevlar, Addix Soft, Super Gravity, Tubeless Easy, 2.60
REAR TIRESchwalbe Hans Dampf Kevlar, Addix Speedgrip, Super Gravity, Tubeless Easy, 2.60
HANDLEBARRace Face Next R 35 Carbon, 800mm
GRIPSCUBE Race Grip 31mm, 1-Clamp
SEAT POSTRockShox Reverb AXS™ 31.6mm (16": 340x100mm; 18": 390x125mm; 20", 22": 440x150mm)
SEATCLAMPCUBE Srewlock Semi Integrated, 34.9mm
SADDLENatural Fit Nuance SL
HEADSETFSA Orbit Z 1.5E ZS, Top Zero-Stack 1 1/2" (OD 56mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
WEIGHT22,6 kg
COLOURcarbon´n´red
ART. NO337302

GEOMETRY

Some people laughed when we said we could build a hybrid enduro bike capable of taking on the world's toughest EWS trails. Well, they're not laughing now. The new Stereo Hybrid 160 HPC rewrites the rules, blending the big-hit ability of a dialled big-mountain machine with the ride-anywhere versatility of Bosch's fourth-generation drive system. There's literally no mountain too high, or too steep, for this bike. Key to its success is a brand-new main frame constructed from carbon. The versatility of this material allowed our engineers to create an entirely new setup - the Modular Battery System - to house the Bosch power unit entirely within the down tube. Hidden by a double-layer cover with shock protection, push-button access and a hidden lock, the new system has freed up enough space for the Stereo Hybrid 160 HPC to accommodate a larger capacity 625Wh battery, for significantly extended range - so you can ride further, higher and faster, confident that you've got the juice to keep going. The trunnion shock mount, big bearings and Boost 148 rear axle of the aluminium rear triangle work with the 1.5in head tube to deliver efficient power transfer and millimetre-perfect steering precision, whilst aggressive geometry gives you the advantage you need to show the trails exactly who's boss. We even remembered to add a bottle cage mount and make it chain guide compatible, so you can tailor your Stereo Hybrid 160 HPC exactly the way you want it. Enduro is exciting, but Bosch hybrid power takes it to a new level. Are you up for it?
